Application
This high speed disperser is primarily used for petrochemical, chemical, pharmaceutical, papermaking, food, adhesive, coating and fine chemical industry applications.
Features
The main body of the explosion resistant high speed disperser is operated in a stable manner so that there is no vibration during the working process.
The fully enclosed-safety work space design can reduce solvent and material loss, and is also environmentally friendly.
The high speed disperser is equipped with pressure and temperature automatic feedback systems in order to ensure safety.
The stirring paddle is made of high strength stainless steel, so that it does not easily get dirty, and is easy to clean when needed.
The explosion proof high speed disperser is equipped with a frequency control device in order to accurately control different material speeds.
Descriptions
The explosion proof high speed disperser can disperse emulsified materials with different viscosity levels. Through the high-speed rotation of the dispersion disk, a strong shear collision and friction is produced between the material and the disk, which can achieve rapid emulsification, dissolving, mixing, and dispersion functions.
Serial number | Item | Size | Unit | Quantity | Notes |
1 | Mixing tank (single layer) | Inside φ 750*600 mm | set | 1 | SUS304 |
2 | Discharging valve | DN 40 | set | 1 | SUS304 |
3 | High strength industrial caster | D125 | set | 4 | Iron coated with PU |
Technical Parameter
Specification: CSH-GF-40HP
Design volume: 265L
Working volume: 100-200L
Maximum loading rate: 82%
Viscosity: 0-1000CPS
Vacuum limit: -0.098 MPA
Total power: ~32KW
Dimensions: about 2500mm* width 1750mm* high 1960mm (rising height~3060mm);
Weight: 3000 KG
Except for the data above, this equipment can be customized to meet specific application needs.
