60L Planetary Mixer

Product details
Our 60L planetary mixer can perform mixing and dispersion tasks nearly anywhere. The unique mixing mechanism, dispersion plate, and stirring paddles achieve complex revolving and rotation patterns with variable frequency adjustment to ensure uniform operation. The materials are subject to strong shear and knead force for optimal mixing. The equipment can also be pressurized or operated under vacuum conditions to eliminate bubbles.

Application
60L planetary mixers are used for the mixture, reaction, dispersion, dissolution, homogenization emulsification of solid - solid, solid - liquid, and liquid - liquid materials. It is widely used in the processing of chemicals, food, pharmaceuticals, building materials, pesticides, etc.

60L planetary mixer is ideally used in the processing of binders, chemical products, plastics, electronics, anaerobic glues, battery fluids, electrode pastes, inks and pigments, sealants and encapsulates, and additives.

Dimensions
Main body: length × width × height = 2000 * 1200 * 2100 / mm
Lifting trip: about 700mm
Mixing bucket: diameter × height = φ510 * 400mm;
Working volume: 60L

Electrical Parts
Dispersed motor: 7.5KW; 380V 50Hz
Dispersion speed: 0 ~ 3000r / min
Mixing motor: 5.5KW; 380V 50Hz
Stirring: 0 ~ 90r / min
Revolution speed: 0 ~ 30r / min
Gas station motor: 0.75KW; 380V 50Hz
Oil station solenoid valve: 50W; 220V 50Hz
